Mazda 323 Familia BF 21/24 Spline Outer CV Joint - HDK MA-004

Description

Outer CV joint for the Mazda 323 BF. HDK part number MA-004.

New old stock. The box has been on a shelf for years. The joint has never been fitted.

Label sizes: 21 teeth inside, a 52 mm seal, 24 outer spline teeth, 65 mm body. No ABS ring.

The box names no car. Our supplier's records give Mazda parts B004-25-600A and B004-22-610. Catalogues put that Mazda number on the 323 BF from 1985 to 1991. Familia is the Japanese name for the same car.

More than one joint fits a 323. Count the splines and measure the seal on the one you are taking off. Or send us your rego and we will match it.

Fitting

  • Fit the new circlip dry and clean.
  • Work grease into the balls and the cage, not just the cup.
  • The axle nut wants the factory torque and a fresh stake or pin.
  • Drive it on full lock at low speed and listen at both ends.
  • Best fitted by a qualified mechanic.

Mazda 323 Familia BF 21/24 Spline Outer CV Joint - HDK MA-004

Product form

Outer CV joint for the Mazda 323 BF. HDK part number MA-004.New old stock. The box has been on a... Read more

1 in stock Dispatch in 1–3 business days

$89.00 Incl. VAT

    • Guaranteed secure & safe checkout. NZ owned & operated.

      shop pay
    • Free shipping on orders of $100 or more
    • Consumer Guarantees Act protection on every order

    Description

    Outer CV joint for the Mazda 323 BF. HDK part number MA-004.

    New old stock. The box has been on a shelf for years. The joint has never been fitted.

    Label sizes: 21 teeth inside, a 52 mm seal, 24 outer spline teeth, 65 mm body. No ABS ring.

    The box names no car. Our supplier's records give Mazda parts B004-25-600A and B004-22-610. Catalogues put that Mazda number on the 323 BF from 1985 to 1991. Familia is the Japanese name for the same car.

    More than one joint fits a 323. Count the splines and measure the seal on the one you are taking off. Or send us your rego and we will match it.

    Fitting

    • Fit the new circlip dry and clean.
    • Work grease into the balls and the cage, not just the cup.
    • The axle nut wants the factory torque and a fresh stake or pin.
    • Drive it on full lock at low speed and listen at both ends.
    • Best fitted by a qualified mechanic.
