Description
Outer CV joint for older turbo Mitsubishis. HDK MI-006, replacing Mitsubishi MB297678.
New old stock that never went on a car. The carton shows the storage, the joint does not.
The box says Mitsubishi turbo and nothing more. Label sizes are A=25, B=50, C=25, D=62. So 25 teeth inside, a 50 mm seal, 25 outer spline teeth and a 62 mm body. No ABS ring here.
Parts catalogues put this joint on late 1980s and early 1990s Mitsubishis, including the Galant, Sapporo and Chariot. The Hyundai Sonata and Lantra of that era share it.
Plenty of joints in this era. Mitsubishi used several. Count the splines on the one you are pulling off and measure the seal. Or send us the plate and we will match it.
Fitting
- Clean the splines right down before the new circlip goes in.
- Work grease into the balls, not just around them.
- Axle nut back up to the figure in the manual.
- Drive it on full lock and listen before you hand it over.
- Best fitted by a qualified mechanic.
